6.Usingapozi-drivescrewdriverandthescrewsprovided,securethetransombrack
etusing
theadjustmentslots.
Note:
Thethirdlockingscrewisnotuseduntilthetransducerhasbeensuccessfullytested.
Mountingthetransducerassembly
Important:
•Onlyperformtheinstallationwithyourvesseloutofthewater .
•DoNOTliftorsuspendthetransducerusingitscable.
•DoNOTovertightenthebolt.Overtighteningmaycausedamagetothetransducer.
1.P ositionthetransducerassemblyinthetransombracket,ensuringthattheratchetgroovesinthe
transombracketarealignedwiththeratchetgroovesinthehangerbracket.
24
