Raymarine M81131 User Manual

7
Contents
This guide contains:
Specifications
Drive specifications
1
Product specifications page 7
2
Installation instructions page 8
3
Maintenance information page 17
Table 1-1: Drive specifications
Performance*
(at nominal voltage)
Type 1 (T1)
M81130 (12 V)
Type 2 short (T2S)
M81131 (12 V)
M81133 (24 V)
Type 2 long (T2L)
M81132 (12 V)
M81134 (24 V)
Maximum boat dis-
placement
10,000 kg
(22,000 lb)
15,000 kg
(33,000 lb)
20,000 kg
(44,000 lb)
Peak thrust 295 kg
(650 lb)
480 kg
(1,050 lb)
480 kg
(1,050 lb)
Maximum stroke 300 mm
(12 in)
300 mm
(12 in)
400 mm
(16 in)
Hardover to hardover
time
(+/- 35º, no load)
11 sec 11 sec 14 sec
Maximum rudder
torque
735 Nm
(6,500 lb.in)
1,190 Nm
(10,500 lb.in)
1,660 Nm
(14,700 lb.in)
Power consumption
(typical average)
18-36 W 48-72 W (12 V)
66-96W (24 V)
Other information (applies to Types 1 and 2 short/long)
protected for use in engine compartments
CE approvals - conforms to:
89/336/EC (EMC), EN60945:1997
94/25/EC (RCD), EN28846:1993
