Specifications
Drive unit
Maximum boat displacement:
Wheel drive:
Tiller drive:
GP Tiller Drive
8,500 kg (18,700 lb)
6,000 kg (13,000 lb)
7,500 kg (16,500 lb)
Helm speed: Wheel drive:
Tiller drive:
9 rpm (designed for systems with 1–3.5 turns lock to lock)
4.0 sec (lock to lock)
Operating conditions:
Wheel drive:
Tiller drive:
-10 °C to +55 °C (14 °F to 131 °F); waterproof to CFR46
0 °C to +60 °C (32 °F to 140 °F)
Overall dimensions:
Wheel drive:
Tiller drive:
outer diameter: 361 mm (14.2 in)
depth: 171 mm (6.7 in) (without spoke clamps)
midstroke length: 620 mm (24.5in); diameter: 44 mm (1.7in)
(see next page for other dimensions)
