16 A65 Installation Manual
.
Making the Cable Connections
The cable connections are located on the back of the display unit as shown below:
Power Input Cable (R08003)
This 1.5m (5 ft) cable is supplied for connecting to your boat’s DC power supply.
DC power is connected at the 3-pin POWER connector on the unit’s connector
panel. The connector (viewed from the outside) and pin functions are shown in
the following diagram and table.
D7722-2
12V Power Supply
Transducer
RS12
Fluxgate Compass
NMEA
Fishfinder
Power Power
A65 Display
GPS
DSM25 Sounder
GPS SONAR AUX NMEA POWER
D7719-1
GPS SONAR AUX NMEA POWER
