34 A65 Installation Manual

Interfaces RS12 GPS Antenna

DSM25 Sounder

NMEA0183, receive and transmit

CompactFlash card slot

Waypoints 1000 waypoints entered via cursor, lat/long or at boat’s posi-

tion.

16 character name can be assigned.

6 different waypoint symbols available

Additional storage available on CompactFlash cards

Waypoint Transfer Waypoints database via NMEA

Man Overboard (MOB

Mode)

Mark placed with course line; readout shows range, bearing,

and lat/long of MOB

Screen functions Full and half screens available dependent on function.

Chartplotter Features

Cartography Navionics Charts on CompactFlash cards

Chart of the world built in

Chart scaling 1/64nm (if cartographic detail is available to 4000nm

Presentation Modes Head up, Course up or North up

(selectable True or Magnetic, Relative or True Motion)

Waypoint Transfer Waypoints database via NMEA or CompactFlash card

Routes A route plan may contain up to 50 waypoints. Up to100

routes can be stored in the units internal memory.

Navigation information Status Bar at top of screen displays chart range, orientation,

relative motion mode, and position data.

Interfacing

DSM connection For communication with DSM25

NMEA Input - NMEA 0183 APB, BWC, BWR, DBT, DPT, GLL, GGA, HDG, HDM,

HDT, RMA, RMB, RMC, RTE, VLW, VTG, WPL, XTE,

and ZDA

NMEA Output - User select-

able

APB, BWC, BWR, DBT, DPT, GGA, GLL, MTW, RMB,

RMC, VLW, VHW, VTG, WPL and ZDA

General
