35
RS12 GPS Sensor
Approvals
CE - conforms to 1999/5/EC
Dimensions: diameter: 3.7 in (95 mm)
height: 1.2 in (30 mm); 2.4 in (62 mm) with pole mount
kit
Weight: 15.3 oz (0.435 kg)
Cable length: 33 ft (10 m)
Receiver type: SD-GPS, WAAS/EGNOS/MSAS ready, 12 parallel chan-
nels
Operating conditions: temperature range: 14°F to 158°F (–10°C to 70°C)
water protection: waterproof to CFR46
Storage conditions temperature range: 14°F to 158°F (–10°C to 70°C)
Frequency 1575.42 MHz ±1 MHz (C/A code), L1
Sensitivity Tracking: –152 dBm
Acquisition: –139 dBm
Signal acquisition: Automatic
Time to first fix (TTTF): Hot start < 6 seconds (typical);
Warm start < 40 seconds (typical);
Cold start < 60 seconds (typical)
Position accuracy: 2 DRMS ~ 2 m 95%
Speed accuracy: 0.1 kts RMS
Geodetic datum: WGS-84
