To ensure sufficient ventilation, keep the spacings shown below free from other surfaces:
10cm / 4” 10cm / 4”
10cm /
4”
5cm / 2”
10cm / 4”
1. AM Loop Antenna Connector
2. Main Speaker Jacks
3. FM Antenna Jacks
Unpacking the system:
You should have:
• one main unit (with 2 speakers);
• one remote control;
• one AM loop antenna;
• T-Type FM antenna wire;
• one user’s guide;
• one safety leaflet.
• owner registration card
R
L
+
-
+
-
75
AM LOOP
1
3
Release tab to lock wire in
the terminal.
NOTE: Make sure the insulation
is completely removed from the
ends of the Antenna and
speaker wires at all connection
points.
Antenna and Speaker
Wire Connection
Push terminal tab down to
insert wire.
2
