REAR BENCH SEAT: functional features
The seat and the seatback may be
folded away to allow bulky objects
to be carried.
First fold away the seat base in order
to then fold away the seatback.
To fold away the seat
Lift up the front of the bench seat
cushion A to the stop.
Ensure that both sides of the seat
base are unlocked.
Then lift up the rear section of the
cushion 1 and tilt the seat base so
that it is next to the front seats.
For safety reasons, carry
out any adjustments
when the vehicle is at a
halt.
To fold down the seatback
Remove the rear headrests (if
fitted).
Ensure that the front seats are
sufficiently forward.
Put the seat belts in their loops B.
Press button 2 on each side and
lower the seatback C.
Before moving the seatback, put
the seatbelt in the belt guide A to
avoid damaging it.
