Renesas RA4E1 User Manual

Renesas RA Family UM-RA4E1, v1 User's Manual
R12UZ0142EE0100 Rev.0.1 Page
14
of 22
Oct.15.23
IIC when changing SW4.1 DIP switch to IIC. This interface may additionally be re-configured in firmware as
several other PMOD types.
This PMOD interface supports +3.3V devices. Please ensure that any PMOD device installed is compatible
with a +3.3V supply.
Table 5. PMOD 1 Connector (J7)
PMOD 1 Connector AIK-RA4E1
Pin
Description
SPI
Signal/Bus
SPI
Description
UART
Signal/Bus
UART
Description
IIC
Signal/Bus
IIC
1
SS
P207
CTS
P207
INT
P000
2
MOSI
P203
TXD
P203
RESET
P203
3
MISO
P202
RXD
P202
SCL
P205
4
SCK
P204
RTS
P204
SDA
P206
5
GND
VSS
GND
VSS
GND
VSS
6
VCC
+3.3V
VCC
+3.3V
VCC
+3.3V
7
GPIO3
P000
INT
P000
INT
P208
8
GPIO4
P209
RESET
P209
RESET
P209
9
GPIO1
P210
GPIO1
P210
CS2
P210
10
GPIO2
P313
GPIO2
P313
SC3
P313
11
GND
VSS
GND
VSS
GND
VSS
12
VCC
+3.3V
VCC
+3.3V
VCC
+3.3V
Figure 9. PMOD 1
5.2.7 PMOD 2
A 12-pin PMOD Type-2A connector is provided at PMOD 2. The Main MCU can act as the UART/SPI
master, and the connected module acts as an UART/SPI slave device. The Main MCU can be used also as
IIC when changing SW4 to IIC. This interface may additionally be re-configured in firmware as several other
PMOD types.
This PMOD interface supports +3.3V devices. Please ensure that any PMOD device installed is compatible
with a +3.3V supply.
Table 6. PMOD 2 Connector (J4)
PMOD 2 Connector AIK-RA4E1
Pin
Description
SPI
Signal/Bus
SPI
Description
UART
Signal/Bus
UART
Description
IIC
Signal/Bus
IIC
1
SS
PB01
CTS
PB01
INT
P001
2
MOSI
P707
TXD
P707
RESET
P707
3
MISO
P706
RXD
P706
SCL
P205
4
SCK
PB00
RTS
PB00
SDA
P206
5
GND
VSS
GND
VSS
GND
VSS
6
VCC
+3.3V
VCC
+3.3V
VCC
+3.3V
7
GPIO3
P804
INT
P804
INT
P001
8
GPIO4
P414
RESET
P414
RESET
P314
