Renesas RA Family
UM
-RA4E1, v1 User's Manual
R12UZ0142EE01
00 Rev.0.1
Page
19
of 22
Oct.15.23
5.3
Special Features Access
5.3.1
Ethernet
Not Supported
5.3.2
M
ICS
AIK RA4E1 Includes t
wo Analog M
ems Microphon
es.
Table
10
. MICs Port Assig
nments
Ethernet Signal
Description
AIK-RA4E1
Port
MIC_AN1
P0
08
MIC_AN2
P009
Figure
15
.
MEMS MICs
5.3.3
CAN/CAN-
FD
At J9 we have the
Controller
Area Network
b
us interface
(CAN).
Table
11
. CAN Port Assignmen
ts
Pin
Description
Signal/Bus
1
VSS
+
3.3
V
2
CRX
P511
CTX
P512
3
DE
P310
4
GND
GND
Figure
16
.
CAN Connecto
r
5.3.4
Camera Module Socket
Not Supported
