RSKRX111 3. Tutorial Project Workspace
R20UT2194EG0100 Rev. 1.00 Page 9 of 27
Jul 3, 2013
3. Tutorial Project Workspace
3.1 Introduction
CubeSuite+ is an integrated development tool that allows the user to write, compile, program and debug a
software project on the RX, 78K, RL and V850 family of Renesas microcontrollers. CubeSuite+ will have been
installed during the installation of the software support for the Renesas Starter Kit product. This manual will
describe the stages required to create and debug the supplied tutorial code.
3.2 Starting CubeSuite+ and Connecting the E1 Debugger
To use the program, start CubeSuite+ from the Windows
TM
Start Menu.
The first time CubeSuite+ is started, the One Point Advice dialog box will be shown:
The One Point Advice dialog box provides some useful tips when using CubeSuite+. Press ‘OK’ to skip the
advice and close the One Point Advice dialog. The user will then be presented with the Start panel.
Under the ‘Open Sample RSK Project’, open a new Tutorial project by selecting the RSKRX111_Tutorial
project template and click on ‘Go’ as shown below. This will save a copy of the RSKRX111_Tutorial project.
