Reolink RLN16-410 User Manual

User Manual
1
Icon
Meaning
Last: Click to show the previous screen of camera’s live image
Next: Click to show the next screen of camera’s live image
Scrollview: Click to start scrolling the live image screen automatically
Display Mode: Choose to view one camera or multiple cameras
Playback: Click to enter the playback page
Back up: Click to enter the backup page
Settings: Click to enter the NVR settings menu
Lock Screen: Click to lock screen, which can set up to require the
password to unlock
Change the Place of the Camera Live View
Manually drag the camera to a blank channel to change the position of the
camera’s live image on the monitor screen.
Use Multiple View
Click to choose options from 1, 4, 8, 9, 16 split-screen views. Note for 8-channel
NVR there’s only options for 1, 4 or 8 split-screen views.
Use PTZ
Click to bring up the PTZ control panel of the camera. Click the arrow in
different direction to pan or tilt the camera.
Click +- on Zoom to zoom in or zoom out the image, and click +- on Focus to
manually adjust the focus of the camera.
Click +- on Movement Speed to set up how fast you want the camera to pan and
tilt.

Reolink RLN16-410 Specifications

General

Number of users	20 user(s)
Maximum resolution	1920 x 1080 pixels
Video input channels	16 channels
Supported resolutions	1024x768, 1280x720, 1280x800, 1280x1024, 1440x900, 1920x1080
Operating system installed	Embedded LINUX
Product color	Black
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	17
Supported network protocols	HTTP, HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Total installed storage capacity	3000 GB
Mobile operating systems supported	Android, iOS
Output current	2.5 A
Output voltage	48 V
AC input voltage	100-240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	HDMI, LAN (RJ-45)
Wi-Fi	No

Weight and Dimensions

Depth	260 mm
Width	330 mm
Height	45 mm
Weight	3000 g
