Reolink RLN16-410 User Manual

Reolink PoE NVR
User Manual
2
1. NVR Introduction
Device Overview
RLN8-410/RLN16-410
Reolink has 16-channe PoE NVR RLN16-410 and 8-channel PoE NVR RLN8-410. Add
cameras to the PoE NVR, you are able to customize your own security systems.
Reolink PoE IP security camera systems feature plug and play, 12MP,4K Ultra HD,
or 5MP/4MP, which are easy to set up and simple to use, for DIY enthusiasts and
beginners. Features of our NVR video system also include excellent night vision,
24/7 continuous recording, local & remote access, and more.
RLN8-410
Power Switch
eSATA
RJ45
Power lnput
Audio Out
USB Port
HDMI Port
VGA Port
Network

Reolink RLN16-410 Specifications

General

Number of users	20 user(s)
Maximum resolution	1920 x 1080 pixels
Video input channels	16 channels
Supported resolutions	1024x768, 1280x720, 1280x800, 1280x1024, 1440x900, 1920x1080
Operating system installed	Embedded LINUX
Product color	Black
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	17
Supported network protocols	HTTP, HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Total installed storage capacity	3000 GB
Mobile operating systems supported	Android, iOS
Output current	2.5 A
Output voltage	48 V
AC input voltage	100-240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	HDMI, LAN (RJ-45)
Wi-Fi	No

Weight and Dimensions

Depth	260 mm
Width	330 mm
Height	45 mm
Weight	3000 g
