Model: M-G1a/M-G1b/M-G1L/M-G1W/R-
G1
Machine Codes:
J017/J019/J021/J023/J018
Slide 156
î Carefully note order and placement of ink lines, as they must be
placed exactly in the order shown above.
Ink Tube Order
6
5
4
3
2
1
6
1
2
3
4
5
Back to Replacement Flow
Note: Be certain that there is no pressure on the connections when installing a
new Ink Carriage Unit â if there is, the ink lines could become detatched.
