SYSTEM SPECIFICATIONS
Ricoh MP C401/MP C401SR
General Specifications
Printing Process Dry Electrostatic Transfer with
Dual Component Magnetic Brush
Development; 4-Drum Method
Scanning Element Full-Color, One-Dimensional Solid
Scanning via CCD
Output Speed 42 ppm (Letter), 40 ppm (A4)
(Copy/Print)
Warm-Up Time 45 seconds with Standard Operation Panel
55 seconds with Smart Operation Panel
First Copy Time 6.7 seconds (B&W);
(Letter/A4) 8.3 seconds (Color)
Recovery Time 4.6 seconds
(to Scan)
Copy Resolution 600 dpi
Document Feeder Automatic Reversing Document Feeder
(Standard) (ARDF)
Original Capacity 50 sheets
Paper Size 5.5" x 8.5" to 8.5" x 14" (A5 – A4)
Custom Up to 49.6" (1260 mm)
Simplex only for Banners
Paper Weight 14 to 34 lb. Bond (52 – 128 g/m
2
)
(Simplex)
Paper Weight 17 to 28 lb. Bond (60 – 105 g/m
2
)
(Duplex)
Exposure Glass 8.5" x 11" (216 x 297 mm)
Quantity Indicator 1 – 999
Input Capacity Standard: 1 x 550 sheets +
100-Sheet Bypass Tray
Maximum: 2,300 sheets
Output Capacity 500 sheets (MP C401);
(Letter/A4) 250 sheets (MP C401SR)
Paper Sizes
Standard Tray 5.5" x 8.5" to 8.5" x 11" (A6 – A4)
Bypass Tray 2.76" x 5.0" to 8.5" x 23.6"
(70 x 127 mm to 216 x 600 mm)
Paper Weights
Standard Tray 14 – 58 lb. Bond/120 lb. Index
(52 – 220 g/m
2
)
Bypass Tray 14 – 68 lb. Bond/140 lb. Index
(52 – 256 g/m
2
)
Duplex Unit 16 – 43 lb. Bond/90 lb. Index
(60 – 163 g/m
2
)
Paper Types Plain Paper, Special Paper, Thick Paper,
Thin Paper, Coated, High-Gloss Coated,
Water-Resistant Paper, Labels, Envelopes,
Letterhead, Color Paper, Preprinted, OHP*
Auto Duplex Standard
Zoom 25% to 400% in 1% increments (Platen);
25% to 200% in 1% increments (ARDF)
Preset Reduction and 155%, 129%, 93%, 78%, 65%
Enlargement Ratios
Dimensions (WxDxH) MP C401: 21.7" x 22.4" x 28"
(550 x 570 x 710 mm) (including ARDF
and Operation Panel)
MP C401SR: 23.8" x 22.4" x 28"
(605 x 570 x 710 mm) (including ARDF
and Operation Panel)
Weight < 176.3 lbs (80 kg) MP C401;
<187.3 lbs (85 kg) MP C401SR
Power Requirements 120 – 127V/60Hz /12A
Power Consumption Less than 1.6 KW (Full System)
Sleep Mode .67W, .88W with Smart Operation Panel
TEC** MP C401: 3.776 kWh/Week,
3.810 kWh/Week with Smart Operation
Panel
MP C401SR: 3.819 kWh/Week,
3.853 kWh/Week with Smart Operation
Panel
*Bypass Tray only.
**Typical electricity consumption by ENERGY STAR program.
Copier Features
Auto Color Selection (ACS), Auto/Manual Density Control, Auto Start,
Batch Mode & SADF Mode, Color Adjustment, Color Creation Modes,
Combine Mode, Copy Mode – Photo Type Selection (Printed, Glossy &
Copied Photo), Cover/Slip/Chapter Sheets, Image Adjustment, Image
Rotation, Job Preset (8), Job Program (25), Sample Copy, Shift/Erase
Margin, Stamps/Numbering, User Codes (1,000)
Printer Controller Specifications (Standard)
CPU Intel Celeron U3405 (1GHz)
Memory 2 GB RAM + 320 GB Hard Disk Drive
(standard/maximum)
Max. Print Speed 42 ppm
Print Drivers Standard PCL5c, PCL6, PS3,
XPS and Universal Driver (via download)
Max. Print Resolution 600 x 600 dpi (PCL5c, XPS);
1200 x 1200 dpi (PCL6, PS3)
Standard Interfaces 1000Base-T/100Base-TX/10Base-T Ethernet,
USB2.0 Type A (2 Ports), USB2.0 Type B
& SD Slot on Operation Panel
Optional Interfaces IEEE 802.11a/g/n Wireless
Network Protocols TCP/IP (IPv4, IPv6), Bonjour
Fonts for PCL 45 Intellifonts, 13 International Fonts
Fonts for PostScript3 136 Roman
Network Operating Windows XP/Vista/7/8/Server 2003/R2/
Systems Server 2008/R2/Server 2012/R2,
Mac OS X 10.6 or later, Citrix MetaFrame/
Presentation Server/XenApp 5.0, 6.0, 6.5,
UNIX Filter for Sun Solaris, HP-UX,
SCO OpenServer, RedHat Linux,
IBM AIX, SAP R/3
Utilities Device Manager NX Lite and Accounting,
Device Manager NX Pro and Enterprise,
Web SmartDeviceMonitor, Web Image
Monitor, @Remote Enterprise Pro
Other Printer Features
Black Over Print, Classification Code, CLP Simulation, PDF Direct Print,
Sample/Hold/Stored and Locked Print, WSD Printer
Scanner Specifications (Standard)
Scanner Resolution 100/200/300/400/600 dpi
(200 dpi default)
Scanning Speed 35 ipm (B&W and F/C @ 200/300 dpi
(Letter/A4) via ARDF)
Scan Area from Platen
Main Scan 8.5" (216 mm)
Sub Scan 11.7" (297 mm)
File Formats Single/Multi Page TIFF, PDF and PDF/A,
High Compression PDF, Single Page JPEG
Scan Mode BW Text/Line Art, Text, Text/Photo, Photo,
Grayscale; Color Text/Photo, Gloss Photo
Scan-to Modes Scan-to-Email (with LDAP support);
Supported Scan-to-Folder (SMB/FTP); Scan-to-URL;
Network TWAIN Scanning; Scan-to-Media
(USB/SD); WSD Scanner
Document Server Specifications (Standard)
Capacity 76 GB (shared with other functions)
Max. Stored 3,000 documents
Documents
Max. Pages 2,000 pages (per document)
9,000 pages (all stored documents)
Facsimile Specifications (Optional)
Type ITU-T (CCIT) G3
Circuit PSTN
Resolution 200 x 100 dpi, 200 x 200 dpi, 400 x
400 dpi (with optional SAF memory)
Modem Speed 33.6K – 2,400 bps with Auto Fallback
Compression Method MH, MR, MMR, JBIG
Transmission Speed G3: Approx. 2 seconds/page (w/JBIG
compression)
G3: Approx. 3 seconds/page (w/MMR
compression)
Scan Speed Up to 33 spm (Letter/A4)
Auto Dialing 2,000 Quick Dials, 100 Group Dials
(500 locations each)
SAF Memory Capacity 4 MB (approx. 320 pages);
Maximum 28 MB (approx. 2,240 pages)
Additional Modes Internet Fax (T.37), IP Fax (T.38),
LAN Fax, Fax Forward to E-mail/Folder,
LDAP Support
Other Facsimile Features
Detection of Misplaced Documents, Double Check Destination,
Fax Output Timer
Security Features
Classification Codes, 802.1.x Wired Authentication, DataOverwriteSecurity
Unit (DOSS), Encryption (Address Book, Authentication Password,
HDD, PDF, SSH, SSL Communication, S/MIME, IPsec Communication),
IP Filtering, Locked Print, Network Protocol On/Off, Quota Setting/
Account Limits, SNMP v3 Support, User Authentication (Windows/
LDAP with Kerberos; Basic and User Codes), Wireless Protected Setup
Finishing
Internal 250-Sheet Finisher Type C400
Paper Sizes 5.5" x 8.5" to 8.5" x 14" (A6 – A4)
Paper Weights 13 – 68 lb. Bond/140 lb. Index
(52 – 256 g/m
2
)
Stack Capacity 250 sheets
Staple Capacity 50 sheets/set (Letter); 30 sheets/set (Legal)
Staple Positions 1 Position; Side Parallel
Optional Hardware Accessories
One Tray Paper Feed Unit (PB1000)
Paper Capacity 550 sheets x 1 tray
Paper Sizes 5.5" x 8.5" to 8.5" x 14" (A6 – A4)
Paper Weights 14 – 58 lb. Bond/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH) 20.4" x 22.1" x 4.7" (520 x 563 x 121 mm)
Two Tray Paper Feed Unit (PB1010)
Paper Capacity 1,100 sheets (550 sheets x 2 trays)
Paper Sizes 5.5" x 8.5" to 8.5" x 14" (A6 – A4)
Paper Weights 14 – 58 lb. Bond/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH) 20.4" x 22.1" x 10.6" (520 x 563 x 271 mm)
One-Bin Tray Type BN1000
(Available with MP C401 only)
Paper Sizes 5.5" x 8.5" to 8.5" x 14" (A6 – A4)
Paper Capacity 100 sheets
Paper Weights 14 – 58 lb. Bond/120 lb. Index
(52 – 220 g/m
2
)
Side Tray Type C400
Paper Sizes 5.5" x 8.5" to 8.5" x 14" (A6 – A4)
Paper Capacity 50 sheets
Paper Weights 16 – 43 lb. Bond/90 lb. Index
(60 – 163 g/m
2
)
Dimensions When 3.3" x 16.4" x 11.6"
Open (WxDxH) (85 x 417 x 295 mm)
FAC49 Cabinet
(Recommended for installation with base model to bring the device up
to the optimal height)
Dimensions (WxDxH) 21.7" x 21.6" x 15.0" (550 x 549 x 381 mm)
Weight 24.9 lbs. (11.3 kg)
FAC50 Cabinet
(Recommended for installation with Paper Feed Unit PB1000
to bring the device up to the optimal height)
Dimensions (WxDxH) 21.7" x 21.6" x 10.3" (550 x 549 x 262 mm)
Weight 20.0 lbs. (9.1 kg)
FAC51 Cabinet
(Recommended for installation with Paper Feed Unit PB1010
to bring the device up to the optimal height)
Dimensions (WxDxH) 21.7" x 21.6" x 7.0" (550 x 549 x 178 mm)
Weight 16.9 lbs. (7.7 kg)
Additional Accessories
Browser Unit Type M10, Copy Data Security Unit Type G, ESP XG-PCS-15D,
Data OverwriteSecurity Option Type H, Fax Connection Unit Type M10,
Fax Option Type M10, File Format Converter Type E, HotSpot MFP Option
Type S, IEEE 802.11 Interface Unit Type O, Memory Unit Type B 32MB,
OCR Unit Type M2, Optional Counter Interface Unit Type A, Smart
Operation Panel Type M10, XPS Direct Print Option Type M10
Consumables
Black Toner Cartridge* 8,300 Pages
Cyan, Magenta & 10,000 Pages
Yellow**
*Toner yield based on 6% coverage.
**Toner yields based on 5% coverage.
For maximum performance and yield, we recommend using genuine
Ricoh parts and supplies.
R3487
Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355, 1-800-63-RICOH
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. © 2014 Ricoh Americas Corporation. All rights
reserved. The content of this document, and the appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products are
shown with optional features. While care has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or adequacy
of the information contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the
conditions and factors affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
www.ricoh-usa.com
