Replaceable Parts
Trays 1-3
1
2
3
CZC142
1. Feed roller
2. Pick-up roller
3. Separation roller
Trays 4-6 (Wide LCD/LCD)
2
3
1
CZC143
1. Pick-up roller
2. Feed roller
3. Separation roller
2. Replacing the Paper Feed Rollers
28
