RIGOL Chapter 2 Performance Verification Test
2-4 RSA3000 Performance Verification Guide
3.004 GHz
2.7 GHz to 3.0 GHz:
<-136 dBm, <-141 dBm
(typical)
3.0 GHz to 4.5 GHz:
<-136 dBm, <-140 dBm
(typical)
Center
Frequency
Maximum
Peak
Minimum
Peak
Average
[1]
Measurement
Result
[2]
Limit
Pass/Fail
PA on
1.04 MHz
100 kHz to 20 MHz:
<-152 dBm, <-160 dBm
(typical)
20 MHz to 2.7 GHz:
<-158 dBm, <-161 dBm
(typical)
2.7 GHz to 3.0 GHz:
<-156 dBm, <-161 dBm
(typical)
3.0 GHz to 4.5 GHz:
<-154 dBm, <-159 dBm
(typical)
504 MHz
2.804 GHz
3.004 GHz
Note
[1]
: Average = (Maximum Peak + Minimum Peak)/2 (dimensionless calculation)
Note
[2]
: Measurement Result = Average – 10 × lg1000 = Average - 30 dB
SSB Phase Noise Test
Specification
SSB Phase Noise
2℃ to 30℃，f
c
= 500 MHz
Carrier Offset
10 kHz offset
<-100 dBc/Hz, <-102 dBc/Hz (typical)
Test Devices
1. Signal Generator × 1
2. Dual-N Cable × 1
3. Dual-BNC Cable × 1
