Appendix RIGOL
RSA3000 Performance Verification Guide
1
Appendix Test Record Form
RIGOL RSA3000 Series Real-Time Spectrum Analyzer Performance Verification Test Record Form
Model:
Tested by:
Test Date:
Displayed Average Noise Level (DANL) Test:
Center
Frequency
Maximum
Peak
Minimum
Peak
Average
[1]
Measurement
Result
[2]
Limit
Pass/Fail
PA off
50 kHz
9 kHz to 100 kHz:
<-120 dBm (typical)
100 kHz to 20 MHz:
<-135 dBm, <-140 dBm
(typical)
20 MHz to 2.7 GHz:
<-138 dBm, <-141 dBm
(typical)
2.7 GHz to 3.0 GHz:
<-136 dBm, <-141 dBm
(typical)
3.0 GHz to 4.5 GHz:
<-136 dBm, <-140 dBm
(typical)
1.04 MHz
504 MHz
2.804 GHz
3.004 GHz
PA on
1.04 MHz
100 kHz to 20 MHz:
<-152 dBm, <-160 dBm
(typical)
20 MHz to 2.7 GHz:
<-158 dBm, <-161 dBm
(typical)
2.7 GHz to 3.0 GHz:
<-156 dBm, <-161 dBm
(typical)
3.0 GHz to 4.5 GHz:
<-154 dBm, <-159 dBm
(typical)
504 MHz
2.804 GHz
3.004 GHz
Note
[1]
: Average = (Maximum Peak + Minimum Peak)/2 (dimensionless calculation)
Note
[2]
: Measurement Result = Average – 10 × lg1000 = Average - 30 dB
SSB Phase Noise Test:
Output Frequency
of Signal Generator
Offset
Measurement
Result
Limit
Pass/Fail
500 MHz
10 kHz offset
<-100 dBc/Hz, <-102
dBc/Hz (typical)
