17
If your head unit has one single pair of RCA
outputs, input them in to the ampliers Channel
1 and 2 input jacks and set the Input Mode
Switch to 2Ch. The ampliers preamp circuitry
will automatically mix all the channels and
output will occur on all 5 channels. There will be
Left and Right balance with constant subwoofer
but no Front to Read Fader Control.
If your head unit has two pairs of RCA outputs,
input Front Left and Front Right in to amplier
Channels 1 and 2 input jacks. Rear Left and Rear
Right in to ampliers Channels 3 and 4 input
jacks. Set the Input Mode Switch to 4Ch. The
ampliers preamp circuitry will automatically mix
all the channels and output will occur on all 5
channels. There will be Left and Right balance,
Front to Rear Fader with constant subwoofer.
If your head unit has three pairs of RCA outputs,
input Front Left and Front Right in to amplier
Channels 1 and 2 input jacks. Rear Left and
Rear Right in to ampliers Channels 3 and 4
input jacks. Subwoofer output in to Channel 5.
If your head unit has only a single subwoofer
output, use a Y adaptor to feed both Channel 5
inputs. Set the Input Mode Switch to 5Ch. The
ampliers preamp circuitry will automatically
mix all the channels and output will occur on
all 5 channels. There will be Left and Right
balance, Front to Rear Fader with independent
subwoofer.
