32
4 X DUAL VC 8 OHM
SPEAKERS WITH
VOICE COILS, ALL IN
PARALLEL
SERIES:
SINGLE VOICE
COIL SPEAKERS
PARALLEL:
SINGLE VOICE
COIL SPEAKERS
Speaker Wiring Chart
2 OHM
TO
AMPLIFIER
2 OHM TO
AMPLIFIER
4 OHM TO
AMPLIFIER
4 + 4
OHM
2
OHM
4
OHM
4
OHM
2
OHM
4 + 4
OHM
4 + 4
OHM
4 + 4
OHM
4 + 4
OHM
