12
Oct. 2010 CUBE-40XL
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100015546 CABINET ASSY 1
# 5100015008 GRILLE 1
CHASSIS
# 5100015016 CHASSIS 1
KNOB, BUTTON
5100004351 R-KNOB 05800-515(SD000043)40A-KBG-10 11
# 5100015020 S-KEYTOP SX BLK 2
5100004353 KEYTOP 40285-501(SD000906) 4
SWITCH
01780101 TACT SWITCH SKQKABD010 6
02897801 SEESAW SWITCH SDDJE13200 94V-0 1
JACK, EXT TERMINAL
05019512 3.5MM JACK 203-HTJ03509ABT 1
13449146 6.5MM JACK YKB21-5012 (W/SW) 1
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 4
SPEAKER, BUZZER
# 5100015948 SPEAKER W1008-432A 1
PWB ASSY
# 5100014936 MAIN BOARD ASSY 1
# 5100016067 PANEL SHEET ASSY 100/117V 1
* This unit includes the following parts.
# ******** Panel Board 1
# ******** Jack Board 1
# ******** Input Board 1
# ******** PS Board Change a fuse for high voltage. 1
DIODE
03349978 LED (RED) L-34HDSL-FPB 6
03349989 LED (GREEN) L-34GDSL-FPB 1
05011067 LED L-3WEGW (153-L-3WEGW) 1
5100003359 LED BL L-34ID (153-L-34IDSLLF) 2
POTENTIOMETER
5100004182 POTENTIOMETER RD901F-40E1-15F-0B10K-00DN6 10
# 5100016162 ROTARY POTENTIOMETER RD901F-40-15F-B10K-09DW6 1
FUSE, FUSE HOLDER
# 5100011084 FUSE MET 1.25 4
# 5100011077 FUSE MET 0.200 2
03670534 FUSE 5ST 1.25 1.25A/250V for low voltage 1
03674001 FUSE 5ST 630MA/250V for high voltage 1
# 5100000592 FUSE HOLDER FC-201 2
To Next Page
