Oct. 2010 CUBE-40XL
Exploded View (Cabinet) Parts List
No. Parts Code Parts Name Description Q’ty
1 5100015008 GRILLE 1
2 SD000017 BADGE 1
3 SD000035 HANDLE WITH ESCUTHEON 1
* This unit includes the following parts.
5100011381 HANDLE 1
5100011382 HANDLE PLATE 1
5100011383 HANDLE HOLDER 2
5100015546 CABINET ASSY 1
* This unit includes the following parts.
4 5100015011 CORNER PROTECTOR 4
5 5100015013 TRIM SASH 1
6 12359104 RUBBER FOOT G-5R 4
8 ******** CABINET 1
7 5100015948 SPEAKER W1008-432A 1
9 ******** CHASSIS ASSY Refer to Exploded View (Chassis) (p. 8). 1
a SD000975 SCREW M4X35 ORIGINAL TRUSS BZC 4
b SD000430 PLANE WASHER D11 D4.1 T1 BLACK/323-BG-405LF 4
c 40230789 SCREW 3X10 OVAL MACHINE BZC 2
d 40011689 SPEED NUT M3 F-TYPE 2
e 40010667 SCREW 4X16 TRUSS TAPPING A FE BZC 24
f 40010367 SCREW M4X25 BINDING MACHINE BZC 4
g SD000370 PLATE WASHER 4.2X10X0.5T FEBC 4
h 40564601 SCREW M5X35 OVALHEAD MACHINE BZC 2
i 5100005098 SCREW 3X16 TRUSS TAPPING A BZC 4
j 40010689 SCREW 4X25 TRUSS TAPPING A FE BZC 8
