9
Oct. 2010 CUBE-40XL
Exploded View (Chassis) Parts List
* Sandwich an Insulating Sheet (#5100015947) between the Heatsink (#5100015021) and Power IC.
* Apply bond to the Heatsink. (#40231345 KONISHI BOND CYEREX100)
No. Parts Code Parts Name Description Q’ty
2 5100014936 MAIN BOARD ASSY 1
* This unit includes the following parts.
1 5100015021 HEATSINK 2
3 5100015016 CHASSIS 1
5100016067 PANEL SHEET ASSY 100/117V 1
* This unit includes the following parts.
4 ******** Input Board 1
5 ******** Panel Board 1
6 ******** Jack Board 1
10 ******** PS Board 1
7 5100004359 CORD HOOK 2
8 5100016080 POWER TRANSFORMER PT-AP018 100/117V 1
5100016081 POWER TRANSFORMER PT-AP018 230/240V 1
9 12369410 CORD BAND 1702B (except for 220VCN) 2
5100010992 CORD COVER 40285-021 (for 220VCN) 1
11 SD000177 AC CORD PSE SP-18A WITH TERMINAL 100V 1
SD000912 AC CORD ASSY SP-20 117V(2P) 1
5100012741 AC CORD 181-BG429-BL 117VBL 2.5M
SD000913 AC CORD ASSY SP-026A 230V(2P) 1
SD000914 AC CORD ASSY SP-61 230VE(2P) 1
SD000915 AC CORD ASSY SP-501 240V(2P) 1
SD001068 AC CORD ASSY SP-18B 115V(2P) 1
5100005807 AC CORD ASSY 181-BG429-CNLF-220VCN 2.5M 1
a 40013067 SCREW M3X8 PAN MACHINE W/SW+SMALL PW ZC 10
b 40565489 SCREW M4X25(302-P8402551LF) PAN MACHINE W/SW BZC 2
c 40010689 SCREW 4X25 TRUSS TAPPING A FE BZC 4
d 40011767 FLANGE HEX NUT M4 FE ZC 1
e 40011889 EXTERNAL TOOTH WASHER M4 FECM 1
40230245 SCREW M4X12 PAN MACHINE W/SW+PW BZC 1
f 40011767 FLANGE HEX NUT M4 FE ZC 2
5100017646 SPRING WASHER 4.1X7.6X1.0 ZC 2
40230245 SCREW M4X12 PAN MACHINE W/SW+PW BZC 2
g 40010301 SCREW M3X20 BINDING MACHINE BZC 2
h 40011756 FLANGE HEX NUT M3 ZC (except for 220VCN) 2
i 22150518 STANDOFF HEX.BOSS 5.5X15 M3 6
To Next Page
