32
Block Diagram
USB
Connector
USB Indicator
LINE IN Jack
MIC/GUITAR
Jack
PEAK Indicator
USB CODEC
[INPUT MONITOR]
Button
PHONES Jack
PHONES Jack

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Roland DUO-CAPTURE and is the answer not in the manual?

Roland DUO-CAPTURE Specifications

General IconGeneral
Audio InterfaceYes
USBUSB 2.0
Sample Rate44.1 kHz, 48 kHz
Bit Depth24-bit
Phantom PowerYes
Max Sample Rate48 kHz
Max Bit Depth24-bit
CompatibilityWindows, Mac
Inputs2 x XLR/TRS combo jacks
Headphone OutputYes
Power SupplyUSB bus-powered
Outputs2 (1/4" TRS)
