29
Recording
The following describes how to record audio from a maximum of four mics connected to the R-44 Combo input
jacks.
fig.mic-1.eps
● Connections
Connect the microphone(s) to the Combo input jack(s).
983
Howling could be produced depending on the location of microphones relative to speakers. This can be
remedied by:
1. Changing the orientation of the microphone(s).
2. Relocating microphone(s) at a greater distance from speakers.
3. Lowering volume levels.
● Phantom power switch
Turn this ON when connecting a phantom-powered condenser mic.
fig.input-analog.eps
● System settings
1. Press the R-44 [MENU] button.
2. In 1 Recording Setup, set Input Select to Analog.
Set the other items in 1 Recording Setup as appropriate
for the recording you want to make.
3. When finished with the setting, press the [EXIT] button
twice to return to the Main screen.
* For more about system settings, refer to “System setup” (p. 60).
● Limiter
Turn this ON if you want to prevent unexpectedly loud sounds or strong attacks from producing clipped noise.
The limiter threshold is -10 dB relative to digital full scale.
The limiter can group and link each channel. See Limiter link (p. 68).
Recording from a connected mic
Adjust the input
LEVEL and SENS
Microphone
Turn this ON
if you're using a
condenser mic.
R-44_e_new.book 29 ページ ２００８年１月７日 月曜日 午後５時８分
