16
Before You Play
Plug the pedal cord extending from the stand into the Pedal
connector located at the back of the HP203’s bottom panel.
fig.PedalCord.eps
1.
Make sure that the [Power] switch located at
the left side of the front panel is off (in the
upward position).
fig.PowerOff-e.eps
2.
Turn the [Volume] knob all the way toward the
left to minimize the volume.
3.
Connect the included power cord to the AC
INLET located at the rear of the bottom panel.
4.
Plug the other end of the power cord into an
AC outlet.
fig.PowerCord.eps
You must use the power cord included with the
HP203.
Getting Ready to Play
Connecting the Pedal Cord
Connecting the Power Cord
OFF
Upward
position
NOTE
HP203_e.book 16 ページ ２００６年１２月８日 金曜日 午前９時３３分
To Next Page
