Roland KC-600 User Manual

11
Jan. 2018 KC-600
Exploded View (Fig.A) Parts List
No. Part Code Part Name Description Q’ty
1 5100057924 R-KNOB BASE + PLATE 11
2 5100016833 BUTTON 710-11033-02-00 1
3 01786012 SEESAW SWITCH JW-M11RKK 1
4 01786045 SW HOLDER AT-217K 1
5 5100046598 POWER SW CUSHION 2
6 5100051443 AC INLET M1909-C 1
7 5100057820 CHASSIS 1
8 5100046593 JACK SPACER 14
5100057296 MAIN SHEET ASSY 1
* This unit includes the following parts.
9 ******** JACK BOARD 1
10 ******** PS1 BOARD 1
12 ******** ROTARY SW BOARD 1
13 ******** PRE BOARD 1
11 5100057927 PWB SPACER RBS-12 3
14 40013812 CAUTION SEAL IEC #142 1
a ******** NUT attached to VR 10
b ******** WASHER attached to VR 10
c ******** NUT M7 attached to SW 1
d ******** WASHER M7 attached to SW 1
e ******** NUT attached to Jack 14
f ******** WASHER attached to Jack 14
o 5100050484 HEX NUT M4 W/SPW ZC 1
40011889 EXTERNAL TOOTH WASHER M4 FECM 1

Roland KC-600 Specifications

General

Power Output	200W
Type	Keyboard amplifier
Channels	4
Outputs	1 x 1/4" (Line Out)
Dimensions	590 x 470 x 445 mm
EQ	3-band
Effects	Reverb
Power Supply	AC 117V
Inputs	4x 1/4-inch line input, 1x XLR mic input, 2x stereo auxiliary input (RCA and 1/8-inch)
