20
Jan. 2018 KC-600
Parts List
fig.-part1-e.eps
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons, parts with parts code ******** cannot be supplied
as service parts.
• Supply is prohibited due to copyright restrictions.
• It is carried in electronic data on the Roland web site.
• The part is made to order (at current market price).
• It can be replaced with an article on the market. (battery or etc.)
• It is a package or an accessory irrelevant to the function maintenance of the main body.
• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).
• Reissuance is restricted.
• It is supplied as an assembled part
(under a different part code).
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100057293 CABINET ASSY W/O SPEAKER 1
# 5100057291 GRILLE ASSY 1
CHASSIS
# 5100057820 CHASSIS 1
# 5100057928 SUB CHASSIS 1
KNOB, BUTTON
5100057924 R-KNOB BASE + PLATE 11
5100016833 BUTTON 710-11033-02-00 1
SWITCH
13119218 ROTARY SWITCH SRBM132400 1
# 5100026336 SLIDE SWITCH SSSU122500 1
01786012 SEESAW SWITCH JW-M11RKK 1
01782623 SWITCH SPUP128100 1
JACK, EXT TERMINAL
5100050453 3.5MM JACK HSJ2000-01-010 1
5100024419 6.5MM JACK PJ-644C-04-EP(610-11020-01-00) 11
5100031944 6.5MM JACK PJ-644C-EP 3
5100029984 XLR CONNECTOR CT3-12FB-EP 1
00122123 XLR CONNECTOR YKF52-5003N 2
5100020312 RCA CONNECTOR HSP-252V3P-04(610-11032-04-00) 1
POWER SUPPLY UNIT
# 5100056488 POWER SUPPLY UNIT 300ASC UNIVERSAL 1
SPEAKER, BUZZER
# 5100058064 SPEAKER W1508-094A 1
# 5100058059 SPEAKER TH08-094A 1
PWB ASSY
# 5100057296 MAIN SHEET ASSY 1
* This unit includes the following parts.
******** JACK BOARD 1
******** PRE BOARD 1
******** ROTARY SW BOARD 1
******** PS1 BOARD 1
# 5100057304 IF BOARD ASSY 1
DIODE
5100003360 LED L-934MBD-F01 (153-L-934MBDLF) 1
POTENTIOMETER
5100026264 ROTARY POTENTIOMETER RK11K1120091 3
5100026263 ROTARY POTENTIOMETER RK11K1120AA4 1
# 5100026268 ROTARY POTENTIOMETER RK14K1220A4P 4
01120156 ROTARY POTENTIOMETER RK14K12B0A5B 10KBX2 2
FUSE, FUSE HOLDER
03670512 FUSE 5ST 5-R 5A/250V FUSE1 on PS1 Board 1
To Next Page
