Roland KC-600 User Manual

16
Jan. 2018 KC-600
Wiring Diagram/Block Diagram
fig.wiring-KC-600.eps@L
CH1
MIC/LINE
BALANCE
HOT
CH1 VOL
CH2 VOL
CH3 VOL
LOW
TONE
CONTR
PHONES
CH4 VOL
COLD
WP2021
CN1
WP2022
WP511
CN13
WP10
CN3
JK2002
JK2001
VR1
VR5
VR2
VR3
VR4
JK2003
VR6
MID
VR7
JK2004
JK2005
JK2006
JK2007
JK2008
JK2009
JK2010
JK2011
JK2012
RSW501
JK2013
SSW2001
CH1
L (MONO)
R
CH2
L (MONO)
R
CH3
L (MONO)
R
CH4
L (MONO)
R
LINE OUT
L (MONO)
R
OUTPUT
SELECT
-15
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE_TR
PHONES L PHONES R MAIN L MAIN R LINE OUT L LINE OUT R
MUTE FET
MUTE TR
+15
+15
-15
L sel
R sel
-15
+15
LINE OUT
BALANCED
L
LINE OUT
BALANCED
R
GND LIFT
JACK BOARD PRE BOARD
ROTARY SW
BOARD
W1
W2
W3

Roland KC-600 Specifications

General

Power Output	200W
Type	Keyboard amplifier
Channels	4
Outputs	1 x 1/4" (Line Out)
Dimensions	590 x 470 x 445 mm
EQ	3-band
Effects	Reverb
Power Supply	AC 117V
Inputs	4x 1/4-inch line input, 1x XLR mic input, 2x stereo auxiliary input (RCA and 1/8-inch)
