Jan. 2018 KC-600
Wiring List
No. Part Code Part Name Description Q’ty
W1 5100057355 WIRING W1 (2547/1007#28) 1
W2 5100057357 WIRING W2 (1007#28 7X150-PHR-SAN-F) 1
W3 5100057308 WIRING W3 (1007#28 4X50-SAN-SAN-F) 2
W4 5100057309 WIRING W4 (1185/1007#28) 1
W8 5100057345 WIRING W8 (1672#18-WHT/BLK) 1
W9 5100048516 WIRING W17 (1015#18-GRN&YEL) 1
W10 5100057310 WIRING W10 (1672#18-BLK) 2
W11 5100057346 WIRING W11 (1015#22-OR/BN/BK/RD) 1
W12 5100057311 WIRING W12 (1185/1007#28) 1
W14 5100057348 WIRING W14 (1007#18 2X280-NVR-NVR-F) 1
W15 5100057349 WIRING W15 (1015#22 2X150-VHR-VHR-F) 1
W16 5100057350 WIRING W16 (1007#24/2547#28) 1
W17 5100058012 WIRING W17 (1015#18-GRN&YEL) 1
W18 5100058013 WIRING W18 (1185#28/1007#26) 1
W19 5100058014 WIRING W19 (1672#18-WHT/BLK) 1
W20 5100058016 WIRING W20 (1672#18-WHT/BLK) 1
W21 5100058018 WIRING W21 (1007#28 3X110-PHR-PHR-F) 1

Roland KC-600 Specifications

General

Power Output	200W
Type	Keyboard amplifier
Channels	4
Outputs	1 x 1/4" (Line Out)
Dimensions	590 x 470 x 445 mm
EQ	3-band
Effects	Reverb
Power Supply	AC 117V
Inputs	4x 1/4-inch line input, 1x XLR mic input, 2x stereo auxiliary input (RCA and 1/8-inch)
