No. Type CTRL 1 function (display) CTRL 2 function (display) CTRL 3 function (display)
5
PHASER
DEPTH (
dP t)N RATE (rAt ) MANUAL (NAn)
Creates modulation by adding a
phase-shifted sound.
Adjusts the depth of modulation. Adjusts the speed of modulation. Adjusts the pitch of the eect sound.
6
TREMOLO/PAN
DEPTH (
dP t) RATE (rAt ) WAVEFORM (trN/PA n)
Cyclically varies the volume or
panning.
Adjusts the amount of change in
volume/panning.
Adjusts the speed of volume/
panning change.
Species the volume/panning
modulation curve. Turn knob to left
to vary the volume, or to the right to
vary the panning.
7
DISTORTION
DRIVE (
dr U)N TONE (ton )N LEVEL (LE U)N
Intensely distorts the sound. Adjusts the degree of distortion. Adjusts the tone. Adjusts the volume.
8
OVERDRIVE
DRIVE (
dr U)N TONE (ton )N LEVEL (LE U)N
Mildly distorts the sound. Adjusts the degree of distortion. Adjusts the tone. Adjusts the volume.
9
FUZZ
DRIVE (
dr U)N TONE (ton )N LEVEL (LE U)N
Adds overtones and intensely
distorts the sound.
Adjusts the degree of distortion. Adjusts the tone. Adjusts the volume.
10
WAH
PEAK (
PE t) RATE (r At ) MANUAL (NAn)
Produces a wah eect.
Adjusts the width of frequencies to
which eect is applied.
Adjust the speed of modulation. Adjusts the pitch of the eect sound.
11
OCTAVE
-2OCT LEVEL (
oC 2) -1OCT LEVEL (oC 1) DIRECT LEVEL (dir)
Adds a pitch at lower octaves. Adds a pitch two octaves below. Adds a pitch one octave below.
Adjusts the volume of the direct
sound.
12
COMP
SUSTAIN (
SU S) ATTACK (Att /rEL)N LEVEL (LE U)N
Makes the sound more consistent. Adjusts the depth of the compressor.
Adjusts the attack. If Limit mode is
on (rE L ), this adjusts the release.
Adjusts the volume.
13
EQUALIZER
LOW (
Lo )N MID (Ni d)N HIGH (Hi )N
Adjusts the volume of each
frequency region.
Adjusts the low-frequency volume. Adjusts the mid-frequency volume. Adjusts the high-frequency volume.
14
BIT CRASH
SAMPLE RATE (
rA t) BIT (bi t) N FILTER (F Lt )
Produces an extreme lo- eect. Adjusts the sample rate. Adjusts the bit depth. Adjusts the lter depth.
15
NOISE GEN
WHITE NOISE (
UH t) DISC NOISE (di S) HUM NOISE (HUN )
Applies a lo- eect, and also adds
noises such as white noise and
record noise.
Adjusts the volume of the “hiss”
noise.
Adjusts the volume of the “pop”
noise.
Adjusts the volume of the “hum”
noise.
16
VINYL SIM
FREQUENCY RANGE (
rn G) NOISE LEVEL (noS ) WOW/FLUTTER (F LU )
Simulates sound heard from an
analog record.
Adjusts the frequency response of
the playback system.
Adjusts the volume of noise.
Adjusts the rotational instability of
the analog record.
17
RADIO TUNING
DETUNE (
tU n) NOISE LEVEL (noS ) BALANCE (b AL)
Simulates sound heard from a radio. Adjusts the tuning drift of the radio. Adjusts the volume of noise.
Adjusts the volume balance between
the direct sound and eect sound.
18
SLICER+FLG
TIMING PTN (
P0 1–P16) (*2) RATE (t32 –t1 ) (*1) FEEDBACK (Fd b)N
Repeatedly cuts the sound. A anger
is added.
The timing at which the sound is cut. Adjusts the length of TIMING PTN. Adjusts the anger depth.
19
RING MOD
FREQUENCY (
Fr q)N SENS (SEn)N BALANCE (bA L)
Gives the sound a metallic character.
Adjusts the pitch of the metallic
sound.
Adjusts the depth to which the
frequency is modulated.
Adjusts the volume balance between
the direct sound and eect sound.
20
CHROMATIC PS
PITCH1 (
- C– CC) PITCH2 (- C – CC) BALANCE (bAL )
A two-voice pitch shifter that
changes the pitch in semitone steps.
Changes pitch 1 in semitone steps
over a +/-1 octave range.
Changes pitch 2 in semitone steps
over a +/-1 octave range.
Adjusts the volume balance between
the direct sound and eect sound.
21
PITCH
PITCH (
Pi t) FEEDBACK (Fdb)N BALANCE (bAL )
Changes the pitch. Adjusts the amount of pitch change.
Adjusts the amount of pitch-shifted
sound that is fed back.
Adjusts the volume balance between
the direct sound and eect sound.
