Quick Start
Turning the Power On
1. Connect headphones or amplied speakers
to the TD-02.
* If amplied speakers are connected, minimize the
volume of the amplied speakers.
* To prevent malfunction and equipment failure, always
turn down the volume, and turn o all the units before
making any connections.
2. Press the [Ā] (POWER) button.
The power to the TD-02 is turned on.
3. If amplied speakers are
connected, turn on the power of
the amplied speakers, and adjust the
volume.
4. Use the [Ć] [ć] (VOLUME)
buttons on the unit to
adjust the volume.
Turning the Power O
1. If amplied speakers are connected to the
unit, minimize the volume of amplied
speakers and turn o their power.
2. Long-press the [Ā] (POWER) button on the unit.
The power to the TD-02 is turned o.
* You must turn o the power by long-pressing the [Ā] (POWER)
button. The settings are not saved if the power supply is
disconnected due to the power cord getting pulled out.
Turning the Power On/O
Using the Auto O Function
The power to this unit will be turned o automatically after
a predetermined amount of time has passed since it was last
used for playing music, or its buttons or controls were operated
(Auto O function). If you do not want the power to be turned
o automatically, disengage the Auto O function (p. 19).
NOTE
¹ Unsaved data is lost when the power turns o. Before
turning the power o, save the data that you want to keep.
¹ To restore power, turn the power on again.
Connecting External Equipment
* To prevent malfunction and equipment failure, always turn down the volume, and turn o all the units before making any
connections.
* Be careful not to get your ngers pinched by the movable parts when you operate the drum sound module holder. If using
this in a location where children are present, be sure to provide adult supervision or guidance.
TD-02
DC IN jack
Connect the included AC adaptor to
this jack.
MIX IN jack (Stereo)
Connect your audio player or
smartphone here. You can perform
along with a song that’s playing on
your smartphone or other
mobile device.
Ø “Playing Along with a Song
from Your Mobile Device”
(p. 11)
OUTPUT/PHONES jack
Outputs the sound. Connect
headphones or an amplied
speaker.
Bluetooth ADAPTOR jack
Connect a BOSS Bluetooth
®
Audio MIDI
Dual Adaptor (BT-DUAL: sold separately)
to play along with the song you hear
on your smartphone that’s connected
wirelessly.
Ø “Attaching the
BT-DUAL” (p. 11)
USB COMPUTER port
If the unit is connected to
your computer via a USB cable
(commercially available), you can
transmit and receive MIDI and audio
data.
Ø “Using This Unit with Computer
Software” (p. 13)
TRIGGER INPUT connector (rear)
Connect the included dedicated
connection cable to this connector, and
use it to connect the pads and pedals.
