Category Setting item Value Explanation
VIDEO OUTPUT
OUTPUT RESOLUTION
AUTO, 480/576i, 480/576p, 720p, 1080i, 1080p,
640 x 480, 800 x 600, 1024 x 768, 1280 x 768,
1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 1200,
1920 x 1200
This sets the output format for video output from the HDMI output
connector and RGB/COMPONENT output connector.
OUTPUT H. POSITION -200–0–500 This adjusts the horizontal position of the main output video.
OUTPUT V. POSITION -200–0–500 This adjusts the vertical position of the main output video
OUTPUT H. SIZE 50.0–100.0–150.0 % This adjusts the horizontal size of the main output video.
OUTPUT V. SIZE 50.0–100.0–150.0 % This adjusts the vertical size of the main output video.
OUTPUT CONTRAST 0–64–127 This adjusts the contrast of the main output video.
OUTPUT BRIGHTNESS 0–64–127 This adjusts the brightness of the main output video.
OUTPUT COLOR 0–64–127 This adjusts the color of the main output video.
OUTPUT COLOR SPACE AUTO, RGB-FULL, RGB-LIMIT, YCbCr
This sets the color space (system for representing colors in video) of the
HDMI and RGB/COMPONENT output connectors.
OUTPUT DVI-D/HDMI AUTO, DVI-D, HDMI
This sets the output mode of the HDMI output connector.
OUTFADE WHITE LEVEL 0–255 This adjusts the white level during output fade.
OUTFADE BLACK LEVEL 0–255 This adjusts the black level during output fade.
MEMORY
SAVE SETTING 1–4 This sets the memory number of the destination for saving.
LOAD SETTING 1–4 This sets the memory number to recall.
MANUAL MODE ON, OFF
When set to “ON,” the settings in memory are recalled while maintain-
ing the settings for the current control positions.
POWER ON LOAD OFF, 1–4
Selecting a memory number (1 through 4) causes the settings at the
selected memory number to be recalled at startup.
MIDI For information on remote control via MIDI, download and refer to the “VR-3EX Remote Control Guide” (PDF) from the following Roland website.
http://www.rolandsystemsgroup.net/
SETUP HDCP ON, OFF When set to “ON,” copyright-protected (HDCP) video can be input.
AUTO CHANNEL SCAN ON, OFF When set to “ON,” channels 1 through 4 are switched automatically.
AUTO SCAN TIME 1–5–120 sec This sets the interval time for automatic switching.
LCD PREVIEW ASPECT 16:9, 4:3 This sets the aspect ratio of the monitor display.
LCD BRIGHTNESS LOW, HIGH This sets the brightness of the monitor.
MENU DISPLAY LEVEL 5–13–15 This adjusts the brightness of the menu display.
BCKGND LEV - OVERLAY 1–12
This adjusts the brightness of overlaid background when the monitor
view is in the in/out mode.
LEVEL METER DISPLAY ON, OFF This turns display of the volume level meter on or o.
NO SIGNAL BACK BLACK, BLUE This sets the color of the background during no video input.
COLOR BAR OUTPUT ON, OFF When set to “ON,” a color bar is output.
AUTO OFF ON, OFF
When set to “ON,” the power to the VR-3EX is automatically turned o
after 240 minutes of no operation.
NTSC/PAL NTSC, PAL This switches between the NTSC and PAL standards.
FACTORY RESET This returns the unit to its factory defaults.
