Roland VR-3EX User Manual

Appendices
55
Main Specications
Roland VR-3EX : AV Mixer
Video Processing
4:2:2 (Y/Pb/Pr), 8 bits (Internal Processing : 480/59.94p when set to NTSC, 576/50p when set to PAL)
Audio Processing
Sampling Rate 24 bits/48 kHz
Input Formats
HDMI Video
(VIDEO IN 1–3)
480/59.94p (when set to NTSC)
576/50p (when set to PAL)
HDMI Video
(VIDEO IN 4)
480/59.94i, 480/59.94p, 720/59.94p, 1080/59.94i, 1080/59.94p (when set to NTSC)
576/50i, 576/50p, 720/50p, 1080/50i, 1080/50p (when set to PAL)
HDMI Audio
(VIDEO IN 1–4)
Linear PCM, 24 bits/48 kHz, 2 ch
RGB/Component
(VIDEO IN 4)
640 x 480/60Hz, 800 x 600/60Hz, 1024 x 768/60Hz, 1280 x 768/60Hz, 1280 x 1024/60Hz, 1366 x 768/60Hz, 1400 x 1050/60Hz, 1600 x 1200/60Hz,
1920 x 1200/60Hz
* The refresh rate is the maximum value of each resolution.
* Conforms to VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60Hz : Reduced blanking
Composite Video
(VIDEO IN 1–4)
NTSC, PAL
Output Formats
HDMI and RGB/
Component Video
(VIDEO OUT)
480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p
640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 1200, 1920 x 1200
* The output format of HDMI and RGB/Component is always the same. When an interlaced format is selected, component signal is output from the
RGB/COMPONENT connector. When a non-interlaced format is selected, RGB signal is output from the RGB/COMPONENT connector.
* The refresh rates of RGB format is 60 Hz when set to NTSC, 75 Hz when set to PAL (excluding 1600 x 1200 and 1920 x 1200. The refresh rate of
these 2 is 75 Hz when set to PAL.)
* RGB formats : Conforms to VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60Hz : Reduced blanking
HDMI Audio
(VIDEO OUT)
Linear PCM, 24 bits/48 kHz, 2 ch
Preview Audio
(PVW OUT)
Linear PCM, 24 bits/48 kHz, 2 ch
Composite Video
(VIDEO OUT)
NTSC, PAL USB Video
720 x 480 when set to NTSC,
720 x 576 when set to PAL, Motion JPEG
Preview Video
(PVW OUT)
480/59.94p when set to NTSC,
576/50p when set to PAL
USB Audio Linear PCM, 16 bits/48 kHz, 2 ch
Input Connectors
Video
VIDEO IN 1–4 (HDMI : Type A 19 pins)
VIDEO IN 4 (RGB/Component : HD DB-15 type)
VIDEO IN 1–4 (Composite : RCA phono Type)
Audio
AUDIO IN 1–4 (XLR/TRS combo type, phantom power)
AUDIO IN 5--6 (Stereo RCA phono type)
AUDIO IN 7/8 (Stereo miniature type)
MIC (Internal stereo microphones)
Phantom Power
DC 48V (unloaded maximum), 10 mA (maximum load)
* Current value per channel
Output Connectors
Video
VIDEO OUT (HDMI: Type A 19 pins)
VIDEO OUT (RGB/omponent : HD DB-15 type)
VIDEO OUT (Composite : RCA phono type)
PVW OUT (HDMI: Type A 19 pins)
Audio
AUDIO OUT L,R (Stereo RCA phono type)
AUX OUT L,R (Stereo 1/4-inch phone type)
PHONES (1/4-inch phone type) (headphones)
PHONES (Stereo miniature type) (headphones)
Other Connectors
MIDI 5 pins DIN type x 2 (IN, OUT/THRU) USB B type x 1 (for streaming and remote control)

Roland VR-3EX Specifications

General

Brand	Roland
Model	VR-3EX
Category	Mixer
Language	English
