Ruijie Reyee RG-RAP6262 Series User Manual

Hardware Installation and Reference Guide 1 Product Overview
2
1 Product Overview
The RG-RAP6262(G) is an outdoor wireless access point (AP) designed by Ruijie Networks for high-speed
wireless networks. Adhering to the latest 802.11ax standard, the AP delivers an access rate of up to
1200Mbps@5G + 575Mbps@2.4G. RAP6262(G) features security, radio frequency (RF) control, mobile access,
Quality of Service (QoS) and seamless roaming. In addition, it can be managed by RG-WS series wireless
access controllers (ACs) to implement wireless data forwarding, security, and access control.
The IP68 design adapts to inclement outdoor environments such as the cold and humidity. This substantially
simplifies installation and maintenance. RAP6262(G) supports PoE to take over challenges in a wide variety of
deployment scenarios, including large-scaled campuses, enterprises, hospitals and Wi-Fi hotspots.
1.1 Technical Specifications
Table 1-1 Technical Specifications of RG-RAP6262(G)
Model
RG-RAP6262(G)
Dimensions (L x
W x H)
222 mm × 200 mm × 166 mm (8.74 in. x 7.87 in. x 6.54 in.)
Access Rate
Built-in antenna: 1775 Mbps
2.4 GHz: up to 575 Mbps
5 GHz: up to 1200 Mbps
Operating
Frequency
802.11b/g/n/ax: 2.4 GHz to 2.483 GHz
802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to
5.850 GHz
(Country-Specific)
Maximum
Transmit Power
500 mW (Country-Specific)
Antenna Type
Built-in omnidirectional antenna
Antenna Gain
2.4 GHz: 3 dBi
5 GHz: 4 dBi
Beam Width
2.4G: E: 30°; H: 360°
5G: E: 30°; H: 360°
Ports
Two 10/100/1000 Base-T Ethernet ports
Uplink LAN 1/PoE port supports PoE
FIT/FAT Mode
Not supported
LED
System and port status indicators
Power Supply
12 V DC/2 A IEEE 802.3at (PoE+)
