Ruijie RG-MTFi-M520 Installation And Basic Configuration Guide

Installation and Basic Configuration Guide Preparation Before Installation
The Average refers to the average limit of harmful gas in one week. The Maximum value is the upper limit of the
harmful gas measured in one week for up to 30 minutes per day.
1.2.3 Anti-interference Requirements
External interference may affect the system in the conductive ways such as capacitive coupling, inductive coupling, and
electromagnetic radiation.
 Keep RG-MTFi-M520 away from like high-power radio stations, radar stations and high-frequency large-current
device.
 Take EMI shielding measures, such as shielded cables.
 Port cables must be managed indoor, so as to prevent port damage caused by lightening.
1.2.4 Installation Position Requirements
 Verify the installation position and the power supply way before the installation. For better maintenance experience,
it is recommended that RG-MTFi-M520 should be installed on the rack above the driver seat. Then please verify the
power cable, antenna specifications and installation positions. Install RG-MTFi-M520 in a position free from
collisions, overheat, direct sunlight, waste, water, oil, and dust, and away from the gasbag controller, stereo
equipment, ABS system, and other electrostatic-sensitive devices.
 Install RG-MTFi-M520 in a hidden, stable, shock-proof, heat-insulated, and water-proof position.
 Secure RG-MTFi-M520 in accordance with Ruijie guidelines to prevent loosening and fall-off.
 Keep ports of RG-MTFi-M520 away from damage caused by external factors. Ensure that LED indicators of
RG-MTFi-M520 can be conveniently observed.
 For better user experience, please install the antennas properly to make the coverage area as large as possible and
minimize the interference. Please install the GPS antenna facing it toward the sky without any obstacle.
1.3 EMI
Various interference sources, from either outside or inside the device or application system, affect the system in the
conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation.
 Take measures to protect the power system from the interference of the electric grid.
 The working ground of the routers should be properly separated and kept as far as possible from the grounding
device of the power equipment or the anti-lightning grounding device.
 Keep RG-MTFi-M520 away from like high-power radio stations, radar stations and high-frequency large-current
device.
 Take EMI shielding measures.
1.4 Installation Tools
 Adjustable wrench
 Electric drill

Ruijie RG-MTFi-M520 Specifications

General

Brand	Ruijie
Model	RG-MTFi-M520
Category	Network Router
Language	English
