8
Know your product
KNOW YOUR PRODUCT
10
11
12
9
1
2
3
4
5
6
7
8
13
14
15
17
16
18
1. Choke lever
2. Fuel cap
3. Throttle lock-out
4. Throttle trigger
5. Upper shaft
6. Knob
7. Bulb
8. Safety guard
9. Lower housing
10. Bump knob
11. Spool
12. Upper housing
13. Trimmer line
14. Lower shaft
15. Front handle
16. Switch
17. Rear handle
18. Starter grip
