23 - English
ASSEMBLY
Fig. 20
TO MOVE THE SAW
See Figure 20.
Holding the leg stand firmly, pull the leg stand toward you
until the leg stand and saw are balanced on the wheels.
Push the saw to the desired location then either open
the leg stand for immediate saw operation or store the
saw in a dry environment.
STORING TABLE SAW ACCESSORIES
See Figure 21.
When not in use, wrenches and the push stick may be stored
on the underside of the saw table, secured by a wing nut.
Additional storage for the push stick is located on top of the
rip fence. To use the storage area, insert the tip of the push
stick into the slot until it clicks into place.
Fig. 21
PUSH STICK
STORAGE
BLADE
WRENCHES
RIP
FENCE
PUSH
STICK
WING
NUT
BLADE
WRENCH
STORAGE
