Press the on/sby/enter key to confirm your selection.
PARAMETERS OF CONFIGURATION
“UNITS +2°C/+10°C”
Parameter
Description
Default
min
MAX
MEASUREMENT INPUTS
/1
Room probe calibration (the parameter is expressed in eighths of degree)
0°C
-40
+99
/6
digital input configuration (0 = open contact, 1 = closed contact)
1
0
1
/7
door open alarm delay time (0 = excluded)
120 sec
0
240
Pr
room probe reading
- °C
-
-
Pc
condenser probe reading
- °C
-
-
COMPRESSOR ADJUSTMENT
r0
adjuster hysteresis (differential)
+4°C
1
15
r1
min. operating setpoint selectable
+2°C
-40
r2
r2
max. operating setpoint selectable
+10°C
r1
+99
COMPRESSOR PROTECTION
C0
compressor activation delay from device start
1 min
0
240
C2
min. delay between compr. stop and subsequent start
3 min
0
240
C5
compressor start cycle time in the event of room probe alarm
10 min
1
240
C6
C5 % where compr. starts in the event of room probe alarm
50 %
0
100
DEFROST
d0
defrost interval (0= excluded)
6 hours
0
99
d3
max. defrost duration (0= defrost never activated)
20 min
0
99
d6
defrosting display (0=actual cell temperature,
1=stopped cell temperature, 2=dEF label)
1
0
2
dE
defrost interval count:
0= actual hours; 1=hours comp. ON; 2= autodeterm.
0
0
1
ALARMS
A0
alarm hysteresis (differential)
+2 °C
1
15
A1
min. operating setpoint alarm (0= excluded)
-2 °C
-40
0
A2
max. operating setpoint alarm (0= excluded)
+15 °C
0
+99
A3
alarm exclusion from device start
120 min
0
240
A4
buzzer activation mode for alarm : 0= always; 1= timer-controlled
1
0
1
A5
time limit for buzzer acoustic signal (only if A4 = 1)
1 min
0
240
A6
temperature alarm exclusion time (only if A1 and/or A2 0)
15 min
0
240
EVAPORATOR FAN ADJUSTMENT
F3
evaporator fan func. during regular operation (0=OFF; 1=ON; 2=parallel with compressor)
1
0
2
F6
temperature below which the condenser fan turns off
20°C
-40
+99
F7
condenser fan differential (relating to F6)
+3°C
1
25
F8
condenser fan func. during regular operation (0=parallel with compr.; 1=ON); also refer to F6 and F7
0
0
1
FA
critical temperature for signalling high condensation temperature
46°C
-40
+99
Fb
critical temperature for high pressure akarm
49°C
-40
+99
“UNITS -25°C/-15°C”
Parameter
Description
Default
min
MAX
MEASUREMENT INPUTS
/1
Room probe calibration (the parameter is expressed in eighths of degree)
-16
(eighths °C)
-40
+99
/2
evaporator probe activation (0=off;1=on)
0
0
1
/3
condenser probe activation (0=off; 1=on)
1
0
1
/6
digital input configuration (0 = open contact, 1 = closed contact)
0
0
1
/7
door open alarm delay time (0 = excluded)
120 s
0
240
/A
setpoint attivazione resistenza porta (solo se /9 = 0)
-7 °C
-40
+99
/b
door resist. activation adjustment hysteresis (only if /9 =0)
2 °C
1
15
/E
Sensor probe visualisation management (0 = normal, 1 = limited from above r0)
1
0
1
/F
defrost relay defrost management (0 = de-energized when the value set with d2 is reached on the
evaporator, 1 = de-energized at the end of time d7)
0
0
1
Pr
room probe reading
- °C
-
-
Pd
defrost/evaporator probe reading
- °C
-
-
Pc
condenser probe reading
- °C
-
-
