10-3

①Powe r N Wi r e ②Powe r L Wi r e ③CN 01-BLC D F AN MOT OR

#1: D C310V

#2: N u l l

#3: Moto r D rivi n g Sig n a l

#4:1 5V

#5: Moto r D rivin g Sig n a l

#6: Feedb ac k Sig n a l

#7: Revers e Sig n a l

④Communi ca tio n A C

Wi r e

#Sk y-bl u e

#Bl a ck

⑤ 4Way-va l v e Wi r e ⑥ CN54-D IS /OU T DOO R /

CON D Temper a tur e

Se n sor

#1:O utdoo r temperatur e

se n si n g

#2: GN D

#3:D is cha rg e tempe r a -

tur e se n si n g

#4: GN D

#5:C on d . temper a tur e

se n si n g

#6: GN D

⑦CN 63-E E V Conn e ct or

#1:E E V dri v i n g sign a l

#2:E E V dri v i n g sign a l

#3:E E V dri v i n g sign a l

#4:E E V dri v i n g sign a l

#5:E E V dri v i n g sign a l

#6:DC 12

⑧CN 30-DO WML OAD

⑨Re ac to r Con n ecto r Wi r e ⑩Compresso r Wi r e

AQV**PSB*
