6-19
Sam sung Electronics
Electrical Part List
OUTDOOR MAIN PCB
AQV**PSB*(DB93-10952A)
Parts Code Location Description Specification Q'TY
0401-001099 D020 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D021 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D030 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D501 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D503 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D510 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D511 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D512 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D514 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D551 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D552 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0402-001097 D156 DIODE-SCHOTTKY B140,40V,1000mA,DO-214AC,TP 1
0402-001192 D153 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1
0402-001192 D154 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1
0402-001192 D155 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1
0402-001298 BD151 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1
0402-001427 D152 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1
0402-001429 D151 DIODE-RECTIFIER US1J,600V,1A,DO-214AC,TP 1
0403-001499 ZD051 DIODE-ZENER
MMSZ5252B,22.8/25.2V,500mW,SOD-
123,TP
1
0403-001499 ZD401 DIODE-ZENER
MMSZ5252B,22.8/25.2V,500mW,SOD-
123,TP
1
0404-001020 D109 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D451 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D452 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D453 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D454 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D491 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D492 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D502 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0406-001204 CD301 DIODE-TVS SMBJ5.0CA,6.4/-/7.25V,600W,SMB 1
0406-001204 CD302 DIODE-TVS SMBJ5.0CA,6.4/-/7.25V,600W,SMB 1
0406-001204 CD303 DIODE-TVS SMBJ5.0CA,6.4/-/7.25V,600W,SMB 1
0407-000123 D611 DIODE-SWITCHING DAN202K,80V,100mA,SOT-23,TP 1
0501-000463 Q651 TR-SMALL SIGNAL
KST2907A,PNP,350mW,SOT-23,TP,100-
300
1
0501-000463 Q652 TR-SMALL SIGNAL
KST2907A,PNP,350mW,SOT-23,TP,100-
300
1
0502-000245 IC156 TR-POWER
KSB1151-Y,PNP,1300mW,TO-126,160-
320
1
0504-000127 Q902 TR-DIGITAL
FJV3102R,NPN,200mW,10K/10Kohm,SOT
-23,TP
1
