6-10
Sam sung Electronics
Electrical Part List
OUTDOOR MAIN PCB
AQV**P*A(DB93-10938A)
Parts Code Location Description Specification Q'TY
0401-001099 D020 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D021 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D030 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D040 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D501 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D503 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D551 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0401-001099 D552 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1
0402-001192 D154 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1
0402-001192 D155 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1
0402-001298 BD151 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1
0402-001427 D152 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1
0402-001427 D153 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1
0402-001429 D151 DIODE-RECTIFIER US1J,600V,1A,DO-214AC,TP 1
0403-001499 ZD051 DIODE-ZENER MMSZ5252B,22.8/25.2V,500mW,SOD-123,TP 1
0403-001499 ZD401 DIODE-ZENER MMSZ5252B,22.8/25.2V,500mW,SOD-123,TP 1
0404-001020 D451 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D452 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D453 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D454 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D491 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D492 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D502 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0404-001020 D553 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1
0407-000123 D611 DIODE-SWITCHING DAN202K,80V,100mA,SOT-23,TP 1
0501-000534 Q301 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,180-390 1
0501-000534 Q651 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,180-390 1
0501-000534 Q652 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,180-390 1
0506-000175 IC801 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 1
0601-002423 LED801 LED SMD,RED,1.6 X 3.2mm,639nm,1.6 X 3.2mm 1
0601-002955 LED803 LED SMD(REVERSE),YEL,1.6x1.5mm,588nm,3.2x1.6x1.1mm 1
0601-002956 LED802 LED SMD(REVERSE),GRN,1.6x1.5mm,3.2x1.6x1.1mm 1
0604-001148 IC301 PHOTO-COUPLER TR,50-600%,200mW,SMD-4,TP 1
0604-001172 IC152 PHOTO-COUPLER TR,150-300,200mW,SOP,TP 1
1201-002946 IC451 IC-OP AMP TSSOP,TR,14P,5x4.4x1.2mm,100,5.5V,-40to+85C,63dB,1,1nA,1nA,1.7mV 1
1202-000104 IC251 IC-VOLTAGE COMP.
393,SOP,8P,150MIL,DUAL,36V,CMOS,PLASTIC,18V,780mW,0to+70C,18V,5mV,250nA,
50NA,30
1
1202-000104 IC611 IC-VOLTAGE COMP.
393,SOP,8P,150MIL,DUAL,36V,CMOS,PLASTIC,18V,780mW,0to+70C,18V,5mV,250nA,
50NA,30
1
1203-005454 IC153 IC-POSI.FIXED REG. LD1117S33-HF,SOT-223,4P,6.5x3.5mm,PLASTIC,3.267/3.333,-40to+125C,0.8,TP 1
2007-000029 R166 R-CHIP 0ohm,5%,1/8W,TP,2012 1
2007-000043 R054 R-CHIP 1Kohm,1%,1/10W,TP,1608 1
2007-000052 R309 R-CHIP 10Kohm,1%,1/10W,TP,1608 1
2007-000066 R155 R-CHIP 20Kohm,1%,1/10W,TP,1608 1
2007-000066 R255 R-CHIP 20Kohm,1%,1/10W,TP,1608 1
2007-000066 R469 R-CHIP 20Kohm,1%,1/10W,TP,1608 1
2007-000066 R472 R-CHIP 20Kohm,1%,1/10W,TP,1608 1
６－１１
