6.Electrical Parts List

INDOOR MAIN PCB( AQV**P*A:DB93-10859G )

6-1

Sams ung Electronics

Electrical Part List

Parts Code Location Description Specification Q'TY

0402-000137 D101 DIODE-RECTIFIER 1N4007,1000V,1A,DO-41,TP 1

2001-000429 R901 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 1

2002-001104 R108 R-COMPOSITION 12Mohm,5%,1/2W,AA,TP,3.4x9mm 1

2002-001104 R109 R-COMPOSITION 12Mohm,5%,1/2W,AA,TP,3.4x9mm 1

2401-000480 C106 C-AL 10uF,20%,50V,GP,TP,5x11,5 1

2401-000807 C111 C-AL 220uF,20%,16V,GP,TP,8x11.5,5 1

2401-002619 C105 C-AL 47uF,20%,25V,GP,TP,5x11,5 1

3812-001283 J10 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J11 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J13 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J14 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J15 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J16 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J17 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J20 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J22 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J23 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J25 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J29 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J3 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J31 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J32 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J33 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J34 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J4 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J5 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J6 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J7 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J8 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 J9 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 JP RY74 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

3812-001283 JPNTC WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 1

6042-000001 E703 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E704 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E705 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E706 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E707 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E708 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E711 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000001 E712 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1

6042-000002 E101 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1

6042-000002 E102 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1

6042-000002 E103 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1

6042-000002 E104 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1
