Samsung MWR-WE13N Installation Manual

18
English
Wired Remote Controller Installation/Service Mode
18
Service Mode
Installation/Service Mode
NOTE
• ‘NONE’ will be displayed if the indoor unit does not support the function. In some cases, the setting may not possible or
it may be not applied though it is set on the unit.
• If communication initialization is needed after the setting, the system will reset automatically and communication will
be initialized.
Main
menu
Sub
menu
Function
Data
bit
Factory
setting
Description Unit
1
1
Wired remote controller
Option setting/checking (1)
Cooling/Heating selection 1 0
0 – Cooling/Heating,
1 – Cooling only
-
Use of wireless remote
controller
2 1 0 – No use, 1 - Use -
MAIN/SUB wired remote
controller
3 0 0 –MAIN, 1- SUB -
Temperature unit 4 0 0 – Celcius(°C), 1 – Fahrenheit(°F) -
2
Wired remote controller
Option setting/checking (2)
Temperature sensor selection 1 0
0 – Indoor unit,
1 – Wired remote controller
-
Use of average temperature 2 0 0 – No use, 1 - Use -
Use of
Auto mode 3 1 0 – No use, 1 - Use -
Temperature display 4 0
0 – Set temperature,
1 - Room temperature
-
AC On/Off button function 5 1
0 – Indoor unit + ERV,
1 – Indoor unit only,
2 – ERV only,
-
Priority Display - Air Purity Level 6 1 0 – No use, 1 – Use -
3 Blade setting/checking
Lock of Blade1 1 0 0 – Unlock, 1 – lock -
Lock of Blade2 2 0 0 – Unlock, 1 – lock -
Lock of Blade3 3 0 0 – Unlock, 1 – lock -
Lock of Blade4 4 0 0 – Unlock, 1 – lock -
4 ERV option Setting/checking
Use of By-Pass mode 1 0 0 – No use, 1 - Use -
Use of Auto mode 2 0 0 – No use, 1 - Use -
Use of air purification mode 3 0 0 – No use, 1 - Use -
Use of external control 4 0 0 – No use, 1 - Use -
5
Room Temperature
compensation
Temperature control reference 1,2,3 0 -9 ~ 40 °C(15~104 °F)
0.1
°C
Temperature compensation
value
4,5,6 0 -9.9 ~ 9.9 °C
0.1
°C
6 Number of connected units
Number of indoor units 1,2 - 0 ~ 16 -
Number of ERVs 3,4 - 0 ~ 16 -
7 Desired temperature increment/decrement (°C only) 1 0 0-1 °C, 1-0.5 °C, 2-0.1 °C -
8
Set/Check ERV Energy saving
operation
Select individual Energy
saving operation
10
0-ON/OFF alternating operation,
1-Outdoor air cooling operation for
different temperature setting
-
Minimum temperature of
outdoor air cooling
3,4 15 5 ~ 15 °C (41~59 °F) °C
0 Factory option setting 1 0
0 – Unchanged
1 – Factory setting
-
