Page #119 background imageLoading...
Page #119 background image
118
Chapter 5.
Troubleshooting
Reinstalling Windows
(Optional)
You can reinstall Windows using the SYSTEM RECOVERY MEDIA
for Windows when Windows is no longer working properly.
(For models supplied with a SYSTEM RECOVERY MEDIA.)
For models supplied with the Samsung Recovery Solution, you
can reinstall Windows using the Samsung Recovery
Solution.
These descriptions are for Windows 7/8 and Windows Vista and for
supported models only.
A SYSTEM RECOVERY MEDIA may not be supplied
depending on your computer model.
If you cannot start Windows, or if you want to delete
all existing data and reinstall Windows, install Windows
according to the descriptions in [Reinstalling when
Windows does not start].
Some pictures may dier from actual product.
These descriptions may dier depending on the operating
system.
Reinstalling Windows may delete data (les and programs)
saved on the hard disk drive.
Make sure to backup all important data. Samsung
Electronics shall not be held liable for any loss of data.
Reinstalling in Windows
1
Insert the SYSTEM RECOVERY MEDIA into the DVD drive.
2
If the Select Windows Installation window appears, click
Install Now. When the Select Update window appears, click
on the relevant item.
If you select Go online to get the latest updates for
installation in the Select Update window, the latest
updates are installed and Step 4 follows. At this time, the
computer must be connected to the Internet.
For Windows 7/8, the screen asking for the operating
system to be installed may appear depending on the
version. If you click the Next button, the screen of Step
3appears.
3
If the User Agreement screen appears, select I accept the
license terms and then click Next.
For Windows 7/8, this screen may not appear depending on
the version.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung NP700Z5AH and is the answer not in the manual?

Samsung NP700Z5AH Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-2450M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-2400 Mobile Series
Processor socket-
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.1 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)25
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® HM65 Express
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity1000 GB
Compatible memory cardsMMC, SD, SDHC, SDXC
Number of HDDs installed1
Display diagonal15.6 \
Display brightness300 cd/m²
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Graphics card familyAMD, Intel
Internal memory6 GB
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 2 + 1 x 4 GB
On-board graphics card ID0x116
Discrete graphics card modelAMD Radeon HD 6750M
On-board graphics card modelIntel® HD Graphics 3000
Discrete graphics memory typeGDDR5
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1300 MHz
Audio systemHD
Speaker power1.5 W
Pointing deviceTouchpad
Front camera resolution (numeric)1.3 MP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version3.0+HS
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Ethernet LAN data rates10, 100, 1000 Mbit/s
Operating system installedWindows 7 Home Premium
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Cable lock slot typeKensington
Battery life (max)- h
Number of battery cells8
AC adapter power90 W
Form factorClamshell
Product colorAluminum
Processor codeSR04Z
Processor ARK ID53452
Processor package size37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth238.5 mm
Width362 mm
Height23.9 mm
Weight2290 g
Depth (imperial)9.3 \
Width (imperial)14.2 \
Height (imperial)0.94 \
