58
Chapter 3.
Using the computer
Connecting an External Display Device
If you connect an external display device such as a monitor, TV,
projector, etc., you can view the picture on the wider screen of the
external device when you give a presentation or watch a video or
movie.
Supported ports are Analog monitor ports (D-SUB), Digital video/
audio ports (HDMI) and Mini DisplayPorts (Mini DP).
The visual quality increases in the order of port connection: HDMI
= Mini DP > D-SUB. Use the port which supports the optimal visual
quality when several ports are available.
Before you start, check the port and cable of the external
display device and then connect the display device to the
computer.
About the connection cable
Users should additionally purchase the necessary connection
cables.
Analog Monitor (D-SUB) Cable
HDMI Cable
Mini DisplayPort (Mini DP) Cable
Connecting to the monitor port (Optional)
You can experience a wider screen by connecting the computer to
a monitor, TV or projector with a monitor port.
You can give better presentations by connecting the computer to
a projector.
The VGA adapter is optional and to be be purchased.
1
For 14 / 15 / 15.6 inch models
Connect the VGA adapter to the monitor port of the
computer. Connect the VGA cable (15-pin) to the connected
VGA adapter and then connect the other end of the VGA
cable to the D-SUB port of the monitor or the TV.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung NP700Z5AH and is the answer not in the manual?

Samsung NP700Z5AH Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-2450M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-2400 Mobile Series
Processor socket-
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.1 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)25
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® HM65 Express
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity1000 GB
Compatible memory cardsMMC, SD, SDHC, SDXC
Number of HDDs installed1
Display diagonal15.6 \
Display brightness300 cd/m²
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Graphics card familyAMD, Intel
Internal memory6 GB
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 2 + 1 x 4 GB
On-board graphics card ID0x116
Discrete graphics card modelAMD Radeon HD 6750M
On-board graphics card modelIntel® HD Graphics 3000
Discrete graphics memory typeGDDR5
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1300 MHz
Audio systemHD
Speaker power1.5 W
Pointing deviceTouchpad
Front camera resolution (numeric)1.3 MP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version3.0+HS
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Ethernet LAN data rates10, 100, 1000 Mbit/s
Operating system installedWindows 7 Home Premium
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Cable lock slot typeKensington
Battery life (max)- h
Number of battery cells8
AC adapter power90 W
Form factorClamshell
Product colorAluminum
Processor codeSR04Z
Processor ARK ID53452
Processor package size37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth238.5 mm
Width362 mm
Height23.9 mm
Weight2290 g
Depth (imperial)9.3 \
Width (imperial)14.2 \
Height (imperial)0.94 \
