2 - 30
9)
Description of Main board
9)-1.
Top
1
DC-in Connector
2
CRT COnnector
3
Power Button
4
RJ45/RJ11 Connector
5
USB Connector(x2)
6
Camera Connector
7
LCD Connector
8
USB FPC Connector
9
Bluetooth Cable Connector
10
Keyboard Connector
11
ICH9
12
Touchpad FPC Connector
13
ICT Connector
14
LED FPC Connector
15
Speaker Connector
16
Express card slot
17
MIC-in Connector
18
CPU Support
-
