12
Adjusting the Product Tilt and Height
―
The colour and shape of parts may differ from what is shown. Specifications are subject to change without
notice to improve quality.
-2.0° (±2.0°) ~ 25.0° (±2.0°)
0 ~ 120.0 mm (±5.0 mm)
• The product tilt and height can be adjusted.
• Hold the top centre of the product and adjust the height carefully.
• The height adjustment has a certain tolerance. Stay within the tolerances when adjusting the
height of the product.
Rotating the Product
―
The colour and shape of parts may differ from what is shown. Specifications are subject to change without
notice to improve quality.
-30.0° (±2.0°) ~ 30.0° (±2.0°)
-2.0° (±2.0°) ~ 92.0° (±2.0°)
To Next Page
