Disassembly and Reassembly _ 7
3. DISASSEMBLY AND REASSEMBLY
3-1. TOOLS FOR DISASSEMBLY AND REASSEMBLY
Tool Type Remarks
Boxdriver
10mm
Heater(1),Tub(12),Fixerscrew(5),Motor(2),
Balance(9)
13mm
ShockAbsorber(2holeseachinleft/right),
Damper(2),Damper(friction2)
19mm Pulley(1)
Double-ended
spanner
10mm
13mm
19mm
Replacedbyboxdriver
Leg
Vicepliers
AToolforprotectingemptyturningofboltor
abrasionfromusingboxdriver
FordisassemblyofSpindrum
Others
(screwdriver,nipper,long
nosepliers)
Commontoolsforservicing
Torquewrench TheToolforassemblyofheaterandTub
-Forinformationaboutpurchasingpartsandtool,pleasevisit
http://www.samsung.com/support
-Forthepartcodeinformation,pleaserefertheattachedle'ExplodedView'.
