8 _ Disassembly and Reassembly
3-2. STANDARD DISASSEMBLY DRAWINGS
► Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.
Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.
 Disassembly
Part Figure Description
Assy Cover Top
1. Remove2screwsholdingtheCoverTopatthe
backoftheunitusing(+)screwdriver.
BACK
FRONT
2. RemovetheCoverTopbyliftingitupafter
pullingitbackabout15mm.
Assy Drawer
1. OpentheDrawerbyhand
2. Whileholdingdownthereleaseleverinsidethe
drawer(redbox),slideopenthedrawer.
3. PulluptheCapRinsetoremoveit.
